How to run Ollama and Open WebUI as a systemd service using Docker Compose

You can host your own alterative to ChatGPT and access it on any device

How to run Ollama and Open WebUI as a systemd service using Docker Compose

I wanted to get started running Large Language Models (LLMs) on my own hardware to learn more about how they work and provide more privacy than a service like ChatGPT. Ollama is an open source, easy to use backend for running local LLMs, and Open WebUI provides a powerful ChatGPT-like interface to Ollama.

What you’ll need

  • A Turing generation or newer Nvidia GPU
  • A Linux distribution on bare metal or on a VM with the GPU passed through
  • The open source Nvidia drivers
    • sudo apt-get install nvidia-open on Debian-based distributions like Ubuntu
    • sudo dnf module install nvidia-driver:open-dkms on RHEL-based distributions
  • Docker
  • The Nvidia Container Toolkit

GPUs with more video memory can use larger AI models, so a card with 24 GB of video memory or more is ideal. But even cards with a small amount of VRAM can can run small models like Gemma 3 1B (a text-only model with one billion parameters).

Check for used or refurbished older models with high amounts of VRAM like the GeForce RTX 3090 or RTX A5000 on sites like eBay and serverpartdeals.com.

Why use Docker for Ollama?

The standard installation method for installing or upgrading Ollama on Linux is to execute an install script that gets downloaded via curl and piped to sh. The install script creates an ollama user, downloads the latest version of ollama, and creates a systemd service to run it at startup.

There are two problems with that approach.

  • A script being downloaded and running commands as root should always be reviewed before running it
  • The Open WebUI container cannot access Ollama, because on Linux Ollama only binds to 127.0.0.1 by default
    • This can be changed by setting Environment="OLLAMA_HOST=172.17.0.1" to the [Service] section of the service configuration
    • But this change would be overwritten each time the install script runs

Plus, I wanted to learn more about Docker anyway.

Docker disadvantages

Using Docker for this does have a couple of disadvantages.

Docker can only use Nvidia GPUs, and the GPU must be reserved by a container, so the GPU cannot be shared across multiple Docker containers. That said, the GPU is still usable by the host outside of Docker. For example, I can run Stable Diffusion projects on the host outside of Docker when the GPU is reserved by ba Docker container but is not actively in use.

See the Docker documentation for more details.

Docker Compose configuration

With that covered, let’s get started. First, create some directories.

1
2
sudo mkdir /opt/openwebui
sudo mkdir /opt/openwebui/ollama_custom

Then create the docker-compose.yml file.

1
sudo nano /opt/openwebui/docker-compose.yml
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
services:
  ollama:
    image: ollama/ollama
    container_name: ollama
    restart: unless-stopped
    ports:
      - "127.0.0.1:11434:11434"
    volumes:
      - ollama:/root/.ollama # Used for Ollama backend storage
      # Used for building and testing custom models
      - type: bind
        source: ./ollama_custom
        target: /root/custom
    environment:
      OLLAMA_HOST: 0.0.0.0  # Allow access from other containers
    deploy:
     resources:
       reservations:
         devices:
           - driver: nvidia
             count: 1
             capabilities: [gpu]
  open-webui:
    image: ghcr.io/open-webui/open-webui
    container_name: open-webui
    restart: unless-stopped
    depends_on:
      - ollama
    ports:
      - "127.0.0.1:3000:8080"
    volumes:
      - open-webui:/app/backend/data
    environment:
      - OLLAMA_BASE_URL=http://ollama:11434
      - WEBUI_URL=https://chat.example.net
      - GLOBAL_LOG_LEVEL=WARNING
volumes:
  ollama:
  open-webui:

The services section

The ollama Service

  • image: ollama/ollama: Uses the official ollama/ollama Docker image, which contains the Ollama server.
  • container_name: ollama: Assigns the container a name of “ollama” for easier identification.
  • restart: unless-stopped: Ensures the container automatically restarts if it stops, unless you explicitly stop it.
  • ports: - "127.0.0.1:11434:11434": Exposes port 11434 of the container to port 11434 on your local machine’a loopback interface. This is the standard port used by Ollama for communication.
  • volumes: - ollama:/root/.ollama: This is crucial for persisting Ollama’s configuration and downloaded models. It creates a named volume called ollama which mounts to /root/.ollama inside the container. This means that even if you stop or remove the container, your downloaded models and settings will be preserved.
  • volumes: - type: bind source: ./ollama_custom target: /root/custom: This uses a bind mount to link a local directory named ollama_custom to /root/custom inside the container. I use this directory to build custom models for testing.
  • environment: OLLAMA_HOST: 0.0.0.0: This sets the OLLAMA_HOST environment variable to 0.0.0.0. By default, Ollama will only listen for connections from 127.0.0.1. Setting this to 0.0.0.0 makes the Ollama server accessible from other containers on the same Docker network, which is necessary for Open WebUI to connect to Ollama.
  • deploy: This section reserves one GPU for the ollama container.

The open-webui Service

  • image: ghcr.io/open-webui/open-webui: Uses the open-webui Docker image from the Ghcr.io registry.
  • container_name: open-webui: Assigns the container a name of “open-webui”.
  • restart: unless-stopped: Similar to Ollama, restarts automatically unless stopped.
  • depends_on: - ollama: This tells Docker Compose that open-webui depends on ollama. Docker Compose will ensure that the ollama container is started before the open-webui container.
  • ports: - "127.0.0.1:3000:8080": Exposes port 8080 of the container to port 3000 the loopback interface on your local machine. This is the port open-webui listens on for web traffic.
  • volumes: - open-webui:/app/backend/data: Creates a named volume called open-webui and mounts it to /app/backend/data inside the container. This is used for storing data related to the open-webui’s backend.
  • environment: - OLLAMA_BASE_URL=http://ollama:11434: Sets the OLLAMA_BASE_URL environment variable to http://ollama:11434. This tells the open-webui container where to find the Ollama server. The use of ollama here is important; Docker Compose automatically resolves ollama to the correct IP address of the running ollama container.
  • environment: - WEBUI_URL=https://chat.example.net: Tells Open WebUI where it can be accessed at.
  • environment: - GLOBAL_LOG_LEVEL=WARNING: Sets the logging level to WARNING so that the logs are not flooded with websocket requests.

The volumes Section

  • The ollama: and open-webui: sections define named volumes. Named volumes are managed by Docker and are the preferred approach for persistent data.

Key relationships & flow

  1. Docker Compose starts the ollama container first.
  2. Once ollama is running, Docker Compose starts the open-webui container.
  3. open-webui then communicates with ollama to access and interact with LLMs.

The systemd service

Configure a systemd service that will start the services defined docker-compose.yml at system boot.

1
sudo nano /etc/systemd/system/openwebui.service
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
[Unit]
Description=An extensible, feature-rich, and user-friendly self-hosted AI platform
Documentation=https://docs.openwebui.com/
Requires=docker.service network-online.target

[Service]
WorkingDirectory=/opt/openwebui
Type=oneshot
RemainAfterExit=yes
user=docker
group=docker

ExecStartPre=/usr/bin/docker compose pull --quiet
ExecStart=/usr/bin/docker compose up -d

ExecStop=/usr/bin/docker compose down

ExecReload=/usr/bin/docker compose pull --quiet
ExecReload=/usr/bin/docker compose up -d

[Install]
WantedBy=multi-user.target

Save the file, then run

1
2
3
sudo systemctl daemon-reload
sudo systemctl enable openwebui.service
sudo service openwebui start

This systend service is designed to pull the latest images every time it starts and restarts, so it might take a few minutes to start or restart. That is normal.

Install and configure the nginx webserver

In the docker-compose.yml file, OpenWeb UI is configured to only listen on 127.0.0.1:3000 for security reasons. If you would like it to be accessible from outside hosts, you should install nginx and configure it as a reverse proxy using the following configuration, replacing your_domain_or_IP with the actual domain or IP address that you are .

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
server {
    listen 80;
    listen [::]:80;
    server_name your_domain_or_IP;

    location / {
        # Add WebSocket support
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";

        proxy_pass http://127.0.0.1:3000;
        proxy_set_header Host $host;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;

        # (Optional) Disable proxy buffering for better streaming response from models
        proxy_buffering off;

        # (Optional) Increase max request size for large attachments and long audio messages
        client_max_body_size 20M;
        proxy_read_timeout 10m;
    }
}

For more details on setting up a nginx reverse proxy, see my blog post on that topic.

The nginx configuration settings for websockets support must be added to any internal or edge server proxying traffic for Open WebUI.

First visit

When you first visit Open WebUI in a browser, you will be prompted to enter an email address and password to create an administrator account.

After that, you will need to select a model. Click on the model picker, and type in the name of the model from the Ollama Library that you want to download and install, then click pull from Ollama.com. Once the model is installed, select it and start chatting!

Sharing access with others

To share access with others, click on your initials in the top right, then click Admin Panel. From there, you will see the Users Overview page. Click on the + to add more users.

Open WebUI supports different authentication methods, such as LDAP and Okta. See the documentation for more details.

Unless the environment variable ENABLE_ADMIN_CHAT_ACCESS is set to False, administrators can read the chats of other users by clicking on the user in the Admin Panel. See the documentation a full list of configuration environment variables.

Granting access to models

Out of the box, users you add won’t have access to any models because all models have their visibility set to Private by default, meaning only those with explicit access other than admins can see the model. There are two ways to fix this:

  • Create a group, assign users to it, and grant the group access to the model
  • Set a the visibility of a model to Public so it can be seen by all users

To add user groups to the access list for a Private model or change the model’s visibility to Public, navigate to the Admin Panel, click on Settings, Models, and then click on a model. Make changes, then click Save & update.
